3D Illuminated Stretch Ceiling

Home / Ceilings / Stretch Ceilings / 3D Illuminated Stretch Ceiling

What are Illuminated Stretch Ceiling ?

Light ceiling solution in the interior. LED illumination of the ceiling and other elements of the interior is a fashionable trend in the design of the premises today. These design ideas will best enable the implementation of LED gratings.

Evenly luminous stretch ceiling - a modern lighting solution in a private interior. LED ceiling tension light creates the effect of natural light. The room as if there is absolutely no ceiling, and there is a pleasant atmosphere of lighting, as in light cloudiness in the summer. Light does not cut eyes, there are no sharp shadows and blind glare.

Evenly luminous ceiling is well suited for small rooms, such as bathrooms, dressing rooms, hallways or corridors, and for living rooms, bedrooms, offices.

The brightness of the light ceiling can be adjusted to a wide range, which allows you to set an atmosphere that matches the mood.

Also, modern light ceilings allow creating high-quality uniform lighting with the effect of daylight in any premises, whether it is a public area of an office, a cafe, a restaurant, a shopping center or a private area for a cozy chat.

For an advertising photo of cars professional photo studios create special lighting conditions using lighting equipment. Light ceiling can create similar conditions directly in the interior of the showroom.

The impressive effect that light ceilings produce will not leave anyone indifferent. This is still a rare solution in the modern world, but with complete certainty it can be said that the concept of light ceilings is the design of the future. At the same time, such lighting is perfectly combined with classical forms and even earlier styles in architecture and design. Light ceilings are ideal for highlighting all the advantages of your interior.

Advantages of 3D Illuminated Stretch Ceiling

The main advantage of such ceilings is their unique texture. For the installation of the construction a special sheet is used - "translucent". It is more transparent in comparison with a conventional film or fabric, which allows to transmit and scatter light. This material belongs to the category of vinyl ceilings and has the following advantages:

Long service life.
Moisture resistance.
Protection against flooding by neighbors.
Ease of maintenance.
Spectacular interior design;
Uniform illumination of the whole room;
Freedom to implement design ideas based on any complex forms;
Large selection of shades of light;
Effective sound insulation;
Energy saving;
Fire safety.

Under the canvas, light sources are installed, as a rule, these are LED strips. Next, the ceiling itself is mounted. This design creates a stunning visual effect: light, passing through a translucent film, gently dissipates throughout the room. Light stretch ceilings in an apartment or office, living room or restaurant will attract the attention of guests and underline the basic idea of interior composition

What are Illuminated Stretch Ceiling ?

Evenly luminous ceiling is well suited for small rooms, such as bathrooms, dressing rooms, hallways or corridors, and for living rooms, bedrooms, offices.

The brightness of the light ceiling can be adjusted to a wide range, which allows you to set an atmosphere that matches the mood.

Advantages of 3D Illuminated Stretch Ceiling

Long service life.
Moisture resistance.
Protection against flooding by neighbors.
Ease of maintenance.
Spectacular interior design;
Uniform illumination of the whole room;
Freedom to implement design ideas based on any complex forms;
Large selection of shades of light;
Effective sound insulation;
Energy saving;
Fire safety.

Application of 3D Illuminated Stretch Ceiling

Stretch light ceiling designs have proven themselves in various areas:

Apartments, penthouses, Homes and lofts
Offices, reception, work areas
Medical and Health Institutions
Car showrooms and Moto Salons
Sport halls and Gyms
Cafes, Restaurants and Bars
Hotels and Motels

Illuminated Stretch Ceiling Design

The design of rooms is constantly evolving. New technologies are being applied that make it possible to realize truly unique ideas. Light stretch ceilings are constructions created using a translucent PVC. At the same time, this type of decoration serves as a decoration of the interior and its functional component.

possibility to create an individual interior;
possibility to increase space;
the opportunity to abandon the standard lighting and chandelier in the middle of the room;
the ability to create soft, diffuse lighting and contrasting clear;
the ability to create a highlight of different colors and a game of color;
the ability to create a soaring effect and "Starry Sky";
simple in care - you can do wet cleaning;
if you select a suspended ceiling type, then you can always replace any panel without dismantling the entire structure.

3D Illuminated Stretch Ceiling material

To create such a design, you can use different types of stretched material. The main differences are in its color and degree of transparency. The darker the color, the less the degree of transparency. The highest rate of light output will be at the white cloth, and the dimmest will be a brown tint.

Very important is what the design will be used for. If it is intended only as an ornamental decoration, then any color of the coating can be used. However, if the ceiling should act as a main lighting or a light window is created in the ceiling, it is better to use a white material .

3D Illuminated Stretch Ceiling Installation

How to install a stretch ceiling ? This is often question asked in our company . Here we share with you installation steps.

Installation of a stretch ceiling usually takes a little time - most often specialists need several hours to carry out these works. Usually the sequence of actions of installers consists of five key stages, each of which we will tell in detail:

1. CEILING PREPARATIONS

Using the laser level, experts make a marking of the ceiling, namely make marks on the walls along the perimeter of the room. Then the points are connected to each other, forming a line along which the baguette will be installed (a special fastener where the pvc is wound up). At the same stage, the technician are determined on what height from the slab ceiling slab should be lowered. Depending on the type of luminaires to be installed and height differences of the home ceiling, this parameter can vary from 2 to 10 cm, but usually the ceiling is lowered by about 5 cm.

2. BAGUET INSTALLATION

On the marked line in the wall holes are drilled about 10 centimeters from each other, after which they are clogged with dowels. In the place where the baguette joint will be located, the step is made less - up to 2-4 cm. Then, with the help of screws, the baguette is fixed to the wall, not allowing the joint to fall on the corner, since during installation of the web, the tension force is large enough and the harpoon can not resist in this place. Thus, when installing the baguette in the corner, it bends at an angle of 90 degrees.

It should be noted that most often the installation of a ceiling made of PVC film is carried out by the harpoon method, when the web is stretched on the profile already fixed on the wall. The main advantage of this method of fastening is that, if necessary, the dismantling and re-installation of the canvas will not be difficult. However, sometimes a staggering method is used, in which the web is fixed in the profile. And although this method is somewhat cheaper, its main drawback is the impossibility of reusing the ceiling. As a consequence, this technology is used less and less.

3. INSTALLATION OF ELECTRICAL CABLES AND LIGHTING ELEMENTS

Before carrying out the work on stretching the canvas on the baguette, it is necessary to determine the places in which the fixtures will be installed, and to mount the installation parts. In addition, all electrical wires must be neatly laid in the cable ducts or corrugated hose and attached to the ceiling.

4. DIRECT STRUCTURE DIRECT INSTALLATION

After the completion of the previous stages of work, the room is prepared: the air is warmed up to 40 degrees. It is this temperature that is optimal for the installation of a stretch ceiling. The canvas itself is heated separately (up to 60-70 degrees) with the help of a construction hair dryer or a heat gun. Thanks to this PVC film becomes elastic, easily stretches and is easily attached to the baguette.

Initially, the film must be suspended in two opposite corners of the room (diagonally), then fixed in the two remaining corners. When the canvas is fixed at the corners, it is attracted to the profile in the middle of each wall, and then pulled on the remaining sections. The fixing process is that the film is pushed into the groove of the profile by a spatula, fixing it firmly in it.

After the end of installation and uniform stretching of the film, the master installs a decorative skirting that hides the fasteners and the gap between the wall and the ceiling.

5. INSTALLATION OF LIGHTING ELEMENTS

After the PVC film has finally stretched and cooled, special thermo rings are glued in the places of the planned installation of the luminaires. Then inside each thermo ring a hole is cut out, to which electrical wires are output, and the luminaire is mounted.

3D Illuminated Stretch Ceiling Specification

Light suspended ceilings without the usual fixtures are mounted using an LED strip. It is installed directly on the concrete base and connected to the network. By means of tapes it is possible to create light lines on the tension ceiling of various shapes. Also, LED lighting can be continuous.

When installing such structures, you can also use fluorescent lamps. But their installation is more complicated, since it involves the installation of several instruments and their integration into one system.

When designing a future ceiling project, you can combine different combinations of light devices of different colors. The design allows creating "light windows", which are used as a primary or additional light source

3D Illuminated Stretch Ceiling installation tools & equipment

Laser tape measure or range finder
Heat gun
Hammer drill
Screwdriver
Laser level
Gas container
Construction Roulette
Suspensions for suspended ceilings
Shoulder blades
Special tools
Folding ladder, scaffolding

How much does a 3D Illuminated Stretch Ceiling cost ?

Before answer the question of what kind of stretch ceiling to choose, it's worth to estimate the cost of the structure. It will depend on the following factors:

Area of the room.
The type and number of lighting devices and openings .
Necessity of implementing a pipe loop.
The material and structural features of the walls.
Type of fabrics.

In most cases, the price of light stretch ceiling with installation is from 650 INR per square feet . The final cost will be known after measuring and making detailed estimates.

How to Clean a 3D Illuminated Stretch Ceiling

Use only the softest napkins and brushes.
Remove all jewelry from hand, otherwise even the smallest stone or curl in the ring can inflict irreparable harm on the ceiling.
Only soft, non-abrasive cleaners. Preferably, the spray is perfect for washing windows with ammonia.
Acetone is gone! It can spoil the film, and for your health it is harmful. PVC film can react in the most unpredictable way to chemicals - change color or discolor, soften, deform into wrinkles. So carefully read the package of the product and then at home we test it in a secluded place, applying a small droplet.
Wash the stretch ceilings very carefully, without pressing, gently, like the baby's skin. And, of course, you can not use a mop or fanatically rub it to a loss of heart rate.
Study the instructions of the ceiling manufacturer. However, some manufacturers allow cleaning the film with a vacuum cleaner, but we do not recommend doing this unless you are sure that the ceiling is fixed very reliably.
